The HIKMICRO LYNX S LE15S handheld thermal monocular camera is equipped with a 256 × 192 infrared detector and an 800 × 600 OLED display. It supports functions of observation, distance measurement, Wi-Fi hot spot, and so on. The high-sensitivity built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly applied to scenarios such as hunting, hiking, law enforcement, searching and rescuing, and etc.
Features:
256 × 192 resolution, 12 μm, high sensitivity detector
Adaptive AGC, DDE, 3D DNR
NETD less than 35 mK (@25°C, F# = 1.0)
800 × 600 resolution 0.32-inch OLED display
Built-in rechargeable lithium battery
Up to 8 hours continuous running
Support hotspot
Specifications
Specification Details
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Max. Resolution 256 × 192
Pixel Interval 12 μm
Response Waveband 8 μm to 14 μm
NETD Less than 35 mK (@ 25 °C),F# = 1.0
Lens (Focal Length) 15 mm
Field of View 11.69° × 8.78° (H × V)°
Digital Zoom 1 ×, 2 ×, 4 ×, 8 ×
Aperture F1.0
Magnification 1.42 to 11.36
Image Display
Display 0.2 inch, LCOS, 720× 540
FFC (Flat Field Correction) Mode Auto, Manual, External Correction
Palettes Black Hot, White Hot, Red Hot, Fusion
Frame Frequency 25 Hz
Smart Function
Hot Spot Yes
Standby Mode Yes
Detection Range 708 m
System
Built-in Memory 8 GB
Built-in Memory Capacity 220,000 pictures
Record Video Yes
Capture Snapshot Yes
Power Supply
Battery Type Lithium battery
Battery Operating Time 8 hours continuous running with Wi-Fi hot spot function off (@ 25 °C), 6 hours continuous running with Wi-Fi hot spot function on (@ 25 °C)
Battery Capacity Display Yes
General
Power 5 VDC/2 A, 1.5 W, Type-C Interface
Work Temperature - 20 °C to 55 °C (- 4 °F to 131 °F)
Protection Level IP67
Dimension 158.3 mm × 61 mm × 57 mm (6.23" × 2.40" × 2.24")
Weight 280 g (0.62 lb)
